详细参数
胶管内径 HOSE ID | 胶管外径 Hose OD | 壁厚 Wall Thickness | 工作压力 Working Pressure | 爆破压力 Burst Pressure | 弯曲半径 Minimum Bend Radius | |||
| Inch | mm | mm | mm | MPa | Psi | MPa | Psi | mm |
| 1/4 | 4.65-5.16 | 7.32-8.43 | 0.89 | 299 | 4330 | 897 | 13000 | 71 |
| 5/16 | 5.97-6.81 | 8.26-9.42 | 0.76 | 276 | 4000 | 828 | 12000 | 76 |
| 3/8 | 7.54-8.38 | 10.36-11.63 | 0.76 | 230 | 3330 | 690 | 10000 | 127 |
| 1/2 | 9.93-10.64 | 12.78-14.10 | 0.89 | 183 | 2660 | 552 | 8000 | 133 |
| 5/8 | 12.57-13.34 | 12.75~16.76 | 0.76 | 161 | 2330 | 483 | 7000 | 177 |
| 3/4 | 15.24-16.51 | 18.62-20.14 | 0.76 | 138 | 2000 | 414 | 6000 | 203 |
| 1 | 21.46-22.99 | 24.64-26.95 | 0.89 | 103 | 1500 | 310 | 4500 | 241 |
| 1-1/4 | 27.80-29.40 | 31.90-33.50 | 1.00 | 41 | 600 | 172 | 2500 | 406 |
